RE850 Binocular Multi-function Handheld Observer

RE850 Binocular Multi-function Handheld Observer

​Onick RE850 binocular multifunctional handheld observation instrument is a small intelligent observation device integrating infrared, micro-light, visible light and laser. It has built-in composite positioning module, high-precision digital electronic compass, ultra-long-distance laser ranging and all-in-one meteorological sensor module, and has multi-spectral fusion function. It can be used for all-weather target positioning reconnaissance, indication, trajectory solution, and can take photos and videos.
Send Inquiry
Description
Parameter
Products Description

Onick RE850 binocular multifunctional handheld observation instrument is a small intelligent observation device integrating infrared, micro-light, visible light and laser. It has built-in composite positioning module, high-precision digital electronic compass, ultra-long-distance laser ranging and all-in-one meteorological sensor module, and has multi-spectral fusion function. It can be used for all-weather target positioning reconnaissance, indication, trajectory solution, and can take photos and videos. It has rich interfaces to build battlefield Internet of Things. It is comfortable to use and easy to carry. It is mainly used for battlefield reconnaissance, trajectory solution, environmental mapping, warning and expulsion.


Product features:

1. 8-in-1 precision target reconnaissance and positioning, self-positioning, target positioning;

2. Ballistic calculation of multiple types of bullets, measurement of meteorological parameters such as temperature, humidity, air pressure, including 267 types of ballistic parameters (supports customization)

Wind deviation can be corrected;

3. Fast and comfortable operation, interface function operation guidance, ergonomic design;

4. The product is fast and stable, IP67 level protection;

5. Small size and light weight;


Application areas:

Reconnaissance, surveillance, outdoor hunting and security protection, etc.


Technical parameter

Image mode
Infrared thermal imaging, low light, full-color visible light, infrared low light fusion (including highlighting, edge, mixing)
Visible light
Resolution 1920*1080
Field of view 44°*34°(W)~2.4°*1.8°(T)
Working illumination ≥0.1Lx (black and white) ≥1.0Lx (full color)
Thermal imaging
Resolution 640*512
Pixel pitch 12μm
Field of view 7.32°*5.86°
Low light
Resolution 800*600
Pixel pitch 8μm
Field of view 7.32°*5.86°
Laser ranging
Distance measurement button Yes
Laser band 1535nm
Measuring range 30m-6km
Positioning component
Positioning mode Beidou/GPS/GLONASS Multi-mode
Electronic compass
Azimuth measurement accuracy 0.5° (RMS)
Pitch angle accuracy 0.4° (RMS)
Laser indication
Invisible laser 850nm 50mw
Visible laser 520nm 30mw
Display
1080p FHP OLED 1080p FHP OLED
Memory
Storage space 100,000 pictures or 48 hours of video
Working time
Continuous working time ≥8 hours
External interface
DC /USB/HDMI/PAL/ DC /USB/HDMI/PAL/
Action distance
Visible light observation performance
Human Detection distance: 12km Detection distance: 9km Identification distance: 4km
Car Detection distance: 14km Detection distance: 11km Identification distance: 6km
Infrared/low light observation performance
Human Detection distance: 5km Detection distance: 2km Identification distance: 1.8km
Car: Detection distance: 7km Detection distance: 3.8km Identification distance: 2km
