NVG-30 Helmet-mounted Monocular Digital Night Vision Device

NVG-30 Helmet-mounted Monocular Digital Night Vision Device

​Onick Owl Anti-theft Hunting Professional Low-light Night Vision Device NVG-30 adopts a high-performance second-generation image intensifier, which has excellent performance, small size, light weight, clear imaging, simple operation and high cost performance. The magnification can be changed by replacing the objective lens (or connecting the multiplier). NVG-30 can be connected to digital cameras, cameras, and camcorders. It can be used with a gun aiming fixture (built-in reticle) or alone. The night vision device has a built-in infrared auxiliary light source and an automatic anti-glare protection system. It is highly practical and suitable for single-soldier combat. It can be worn with a helmet to assist night walking and night driving. The monocular design allows users to have a strong overall control ability in the dark and better respond to emergencies. It is widely used in military observation, border and coastal defense reconnaissance, public security inspection, surveillance, customs drug control, anti-smuggling, navigation and other dark environments.
Send Inquiry
Send Inquiry
Description
Parameter
Products Description

Onick Owl Anti-theft Hunting Professional Low-light Night Vision Device NVG-30 adopts a high-performance second-generation image intensifier, which has excellent performance, small size, light weight, clear imaging, simple operation and high cost performance. The magnification can be changed by replacing the objective lens (or connecting the multiplier). NVG-30 can be connected to digital cameras, cameras, and camcorders. It can be used with a gun aiming fixture (built-in reticle) or alone. The night vision device has a built-in infrared auxiliary light source and an automatic anti-glare protection system. It is highly practical and suitable for single-soldier combat. It can be worn with a helmet to assist night walking and night driving. The monocular design allows users to have a strong overall control ability in the dark and better respond to emergencies. It is widely used in military observation, border and coastal defense reconnaissance, public security inspection, surveillance, customs drug control, anti-smuggling, navigation and other dark environments.

Product features:

1. 11” ultra-clear large window, comfortable viewing without shadows

2. 80-120m full black image viewing distance

3. Ultra-clear conceptual resolution, clear imaging, large field of view

4. Ultra-wideband infrared anti-reflection film, clear day and night black and white/color effects

5. Supports photo recording, you can share the observation screen at any time

6. 3x magnification, effectively enlarge the observation field of view when watching

7. IP66 biological waterproof and dustproof, can work normally in -40℃~50℃ environment

Application Field

It is suitable for military observation, border and coastal defense reconnaissance, public security surveillance, evidence collection, customs anti-smuggling, etc. in the night without lighting environment. It is an important tool for public security departments, armed police forces, special police forces, and guard patrols.


Technical parameter
Optical magnification1x
Digital magnification3x
Objective diameter17.5mm
Eyepiece typewith visibility adjustment
Field of view25.5° x14.5°
Visibility adjustment±5
Focal length20mm
Focus adjustmentobjective lens adjustment
Nearest focal length250mm
Exit pupil distance20mm
Exit pupil diameterØ7
Lens coatingultra wideband infrared anti-reflection film
Optical resolution≤11"
Camera typeCMOS
Camera pixel1920*1080
Sensitive size1/2"
Lighting infrared wavelength850nm/940nm
Minimum illumination10-4LUX
Infrared power1W
Infrared light illumination adjustmentlevel 3
Display image resolution1280*720
Display size/type0.38 Lcos
White balanceAutomatic
Display color modeblack and white, fluorescent green
Operating temperature-40℃ -+ 55℃
Working humidityMaximum 70%
Storage temperature-50℃ - +70℃
Operating voltage3.6V-4.2V
Battery type18650x1
Charging power supplyexternal
Battery lifemore than five hours
Video outputwifi
Waterproof performanceIP66
USB portNone
Photo functionYes (App)
Audio and video recording functionYes
Screen brightness adjustment functionYes
Lighting brightness adjustment functionYes (App)
Photo, video, playback and deletion functionsYes (App)
Time setting functionYes
Color schemeBlack
Size (mm)100x78x65
Weight (g)237g

NVG-30 Helmet-mounted Monocular Digital Night Vision Device

NVG-30 Helmet-mounted Monocular Digital Night Vision Device

NVG-30 Helmet-mounted Monocular Digital Night Vision Device

NVG-30 Helmet-mounted Monocular Digital Night Vision Device

NVG-30 Helmet-mounted Monocular Digital Night Vision Device
