5000X all-round multi-function long-distance high-precision laser rangefinder

5000X all-round multi-function long-distance high-precision laser rangefinder

Onick Optics has launched another masterpiece! Onick 5000X is a full-range multifunctional long-distance portable laser rangefinder with laser distance measurement, height measurement, angle measurement, speed measurement, span (any two points in space), GPS function (detachable GPS), current point, target point positioning, air pressure, temperature, area, volume measurement, Bluetooth, USB, Typec interface and other powerful functions. The performance and accuracy can meet your high demands in various working environments!
Send Inquiry
Send Inquiry
Description
Parameter
Products Description

All-round multi-function long-distance high-precision laser rangefinder
Onick Optics has launched another masterpiece! Onick 5000X is a full-range multifunctional long-distance portable laser rangefinder with laser distance measurement, height measurement, angle measurement, speed measurement, span (any two points in space), GPS function (detachable GPS), current point, target point positioning, air pressure, temperature, area, volume measurement, Bluetooth, USB, Typec interface and other powerful functions. The performance and accuracy can meet your high demands in various working environments!

At the same time, Onick 5000X uses a military-grade metal shell while ensuring the excellent use function of the product. It is durable, compact and lightweight. 5000X has a transparent and clear OLED LCD two-color display with black and red font switching. The red font is used in a darker environment, and you can read accurate measurement data while aiming at the target. The innovative lens coating and high light transmittance make the observation effect clearer.



Product features:

1. Measuring distance 5000m, accuracy 0.1m

2. Powerful functions, ranging, height measurement, angle measurement, speed measurement, span (any two points in space), sag measurement

3. With azimuth and GPS function (detachable GPS), display current point, target point positioning

4. Temperature, humidity detection, air pressure and altitude detection, area and volume measurement

5. With Bluetooth, support APP data transmission, APP control measurement, USB Typec interface, OLED black, red two-color display

6. Ergonomic design, compact and lightweight


Application areas:

Electric power construction maintenance, power supply site inspection, line inspection (cable height), power line selection survey and design, forestry survey, security and police use, geological exploration, field hunting, railway construction survey, installation survey, high-rise building monitoring, high-speed rail passenger line track construction, water conservancy and hydropower survey, water conservancy river survey, oil pipeline, archaeological research, mine survey, railway line selection, land and resources survey, etc.




Technical parameter


ModelOnick 5000X
Range0m-5000m
Distance accuracy±0.1m (15-300m) ±0.2m (300-600m) ±0.3m (600-1000m) ±1m (1000-5000m)
Distance displaybuilt-in OLCD display
Magnification8.0X
Field of view6.8°
Kilometer field of view110m
Eyepiece aperture22mm
Exit pupil diameter4.2mm
Objective & emission aperture32mm
Receiving aperture32mm
Exit pupil distance24mm
Clarity adjustmentYes
Diopter range (vision)± 5dpt
Transmittance85%
CoatingMulti-layer optical coating
Objective lens focus compensationYes
Focus methodEyepiece focus
Laser eye safetyYes
Vertical angle±0.1°
Azimuth±1°
Temperature measurement range-45°-130°
Data storage100 groups
Dynamic speed measurement18-300km/h
Static speed measurement0-300km/h
Azimuth range0 degrees-360 degrees
Vertical angle range-90 degrees +90 degrees
Charging methodUSB Type interface
Battery life>3000h
Working temperature-20C to +60C
Storage temperature-40C to +80
Tripod interfaceYes
Size115*105*65 mm
Measurement functionhorizontal distance, straight distance, vertical distance, angle measurement, two-point height measurement, three-point height measurement, distance between any two points in space, horizontal distance between two points in space, azimuth measurement, speed measurement, volume area measurement, Bluetooth APP data transmission, temperature and humidity, sag measurement, air pressure altitude, GPS positioning
TripodSupport
Power supply18650 2000mah, 3.7v
