RE60 outdoor search thermal imaging night vision device

The Onick RE60 is a pocket-sized infrared imaging monocular that enables outdoor observation and target tracking at night and in low-light conditions.The Onick RE60 can clearly display infrared images of the surrounding conditions, helping you see people, objects and animals clearly. The RE60 is easy to use and has both still image and video recording capabilities, making it a perfect companion for both wilderness hikes and suburban walks.
Send Inquiry
Send Inquiry
Description
Parameter
Products Description

The Onick RE60 is a pocket-sized infrared imaging monocular that enables outdoor observation and target tracking at night and in low-light conditions.

The Onick RE60 can clearly display infrared images of the surrounding conditions, helping you see people, objects and animals clearly. The RE60 is easy to use and has both still image and video recording capabilities, making it a perfect companion for both wilderness hikes and suburban walks.

Product features:

1. Upgraded image quality, enhanced details, clear outlines, and sharp images;

2. 50HZ high frame rate is sensitive and smooth, high-quality moving target observation, and dynamic picture capture is not delayed;

3. Laser indication and cross cursor, quickly locate the target and confirm the observed object;

4. Distance measurement estimation, dynamic measurement assistance, estimate the distance of the target;

5. Support WIFI image transmission, real-time browsing, video recording and photography on mobile phone APP;

6. Automatic hotspot tracking, automatic locking and tracking of high-temperature targets; support picture-in-picture, see the details of the target clearly;

7. Lightweight and portable: small size, one-handed operation, IP66 protection level, 1 meter drop resistance.

Application areas:

Hunting: Human eyes are restricted by light at night, and the viewing distance and range will be reduced, and the same is true for other animals. RE60 handheld thermal imaging can magnify the light source at night. Hunters can easily see the surrounding targets with the help of thermal imagers, easily find prey and will not be discovered by prey.

Maritime navigation: At night or in foggy weather, RE60 handheld thermal imaging can assist navigators in observing the channel conditions and avoid collision accidents.

Security investigation: RE60 handheld thermal imaging can assist the troops in patrolling and monitoring the border, effectively preventing smuggling, illegal immigration and other crimes.

Fire search: RE60 handheld thermal imaging can penetrate smoke and clearly image heat, which can help firefighters observe injured people and high-temperature areas outside the fire scene and improve rescue efficiency.

Personal security: RE60 handheld thermal imaging can protect your home and private territory from illegal intrusion, theft and other illegal acts at night.


Technical parameter

model

RE60

Detector performance



Detector type

Uncooled focal plane

pixel

384×288

Image function

























Field Angle

14°*10.5°

Focus Distance

25mm

Noise equivalent temperature difference

<50mk@30℃

Frame frequency

50HZ

Focusing

Manual focus

Electron doubling

2X,3X,4X

Wavelength range

8-14μm

Image transmission

WiFi real-time image transmission
    Support mobile APP image browsing, photography, video and other functions

Cross cursor

There are

Hot spot tracking

There are

Laser indication

There are

picture-in-picture

There are

ranging

There are

Image display





display

Color 1280*960

Image polarity

Black heat, white heat, red heat, false color (iron heat)

Visibility control

Adjust by knob

Power supply system







Battery type

Lithium battery, rechargeable

Battery operating time

5 hours of continuous work

Charging type

Support USB charging, can be connected to external charging bank power supply

External power supply

DC5V/2A(Micro USB)

Environmental parameter







Operating temperature

-20℃- +50℃

Storage temperature

-40℃- +60℃

Class of protection

IP66

fall

1 M

Physical characteristics



weight

0.45kg

dimension

<190x70x70mm

port





Power interface

There are

Video output

PAL

USB

External charging

Observation distance

Detection range

700m people(1.8x0.5m);1100m car(2.3x2.3m)

Recognition distance

350m people(1.8x0.5m);560m car(2.3x2.3m)
