FZS1000 Anti-surveillance detector

FZS1000 Anti-surveillance detector

Onick FZS1000 anti-surveillance detector is a handheld "cat‘s eye" detection device that integrates search, detection and interference based on the principle of the "cat‘s eye" effect. It integrates a low-light camera, a laser detection unit and an interference suppression unit. It can monitor the surrounding environment day and night, actively emit invisible lasers to scan those suspicious areas,
Send Inquiry
Send Inquiry
Description
Parameter
Products Description

Onick FZS1000 anti-surveillance detector is a handheld "cat's eye" detection device that integrates search, detection and interference based on the principle of the "cat's eye" effect. It integrates a low-light camera, a laser detection unit and an interference suppression unit. It can monitor the surrounding environment day and night, actively emit invisible lasers to scan those suspicious areas, and if there are suspicious optoelectronic equipment, it can capture them at the first time. For this reason, we have developed a special software algorithm that can efficiently filter background noise and highlight suspicious targets to help users make further identification. A laser suppression system is integrated inside it, so that after locking the target, the user can manually/automatically emit high-power lasers to suppress it, temporarily losing its attack capability. Its built-in laser ranging unit and digital compass unit also give it stronger environmental perception capabilities. Obtaining data such as the distance, azimuth, and pitch angle of the target can help users lock on to those targets that pose a threat more quickly, providing key data for security departments to eliminate threats.


Onick FZS1000 anti-surveillance detector is mainly used to search and detect suspicious targets that are using optical equipment so as to implement laser interference and suppression in time. It can also be used to find hidden snipers, important occasions security protection, VIP customers' personal safety, anti-surveillance privacy protection, etc.

Product features:

1. A handheld detection and counter-reconnaissance device that integrates search, detection and interference

2. Built-in laser rangefinder and electronic compass to obtain the distance, azimuth and elevation of the target

3. Integrated low-light camera, laser detection unit and interference suppression unit

Application Field

Public security, armed police, military and other special services to achieve all-weather effective observation of specific areas or targets, and quickly discover, identify and track targets of concern; It is also suitable for water conservancy, fire protection, power and oil industries to achieve day and night monitoring of specific areas or equipment.


Technical parameter


Product model

Onick FZS1000

system parameter

Weight

≤ 2kg

Size

≤ 180x110x290mm

Start time

≤ 5

Continuous working hours

6h (at room temperature)

working temperature

-40 ° C~+55C

storage space

32G

Optical parameters

Low light detector resolution

1920x1080

Field of View (FOV)

≥ 7 ° (flat) x 5 ° (vertical)

Magnification rate

4x

Visual adjustment

5SD~+2SD

Observation distance

Day ≥ 1000m , Night ≥ 350m

Detection laser

Daytime detection distance

≥ 1200 (20mm ≤ sight aperture ≤ 50mm);≥ 2500m (sight aperture ≥ 50mm)

Night detection distance

≥ 1800m20mm ≤ sight aperture ≤ 50mm); ≥ 4000m (sight aperture ≥ 50mm)

Detection probability (automatic identification)

≥ 90%

Detection field of view

≥ 3 °

Detecting laser wavelength

≥ 800nm

Interference laser

power density

0.5mW/cm²~1.25mW/cm²

Spot diameter

≥ 50cm (within a distance range of 50m (excluding) to 1000m)

safe distance

≤ 50m (for targets within 50m, no interfering laser is emitted)

laser ranging

Ranging range

3000m

Distance measurement accuracy

±2m

Accurate measurement rate

≥ 98%

Repetition frequency

1Hz

Electronic compass

Global Positioning System

GPS/GLONASS/GELILEO

Direction angle

0~360*

Repetition frequency

± 90 °

Repetition frequency

≤ 0.5 ° (RMS, host tilt angle range -15 °~15 °)
