RM-312  Thermal Imaging Scopes & Infrared Scopes

RM-312 Thermal Imaging Scopes & Infrared Scopes

The 723 series thermal imaging scope has onick RM-312, which can match guns with different ranges. Among the products of the same level, RM has the characteristics of small size, light weight, low power consumption, long recognition distance and high reliability. The built-in image transmission module can be wirelessly connected to the head-mounted device, which is convenient for concealed observation and shooting. The operation is simple and reliable, with automatic gun calibration and probability ranging functions.
Send Inquiry
Description
Parameter
Products Description

The 723 series thermal imaging scope has onick RM-312, which can match guns with different ranges. Among the products of the same level, RM has the characteristics of small size, light weight, low power consumption, long recognition distance and high reliability. The built-in image transmission module can be wirelessly connected to the head-mounted device, which is convenient for concealed observation and shooting. The operation is simple and reliable, with automatic gun calibration and probability ranging functions.


Features

● Wireless Image Transmission

● IP67 Water And Dust Proof

● Single Roller Operating

● Eye Cup Preventing Light Leaking

● Low Power Consumption

● Auto Zeroing

● Ultra-Far Vision

● High Reliability


Application Fields:

It can record and take pictures, record and restore the scene, and can be used for patrol, law enforcement, search and rescue, drug smuggling, and pursuit of fugitives. It is suitable for special forces such as public security, armed police, and the army to achieve all-weather effective observation of specific areas or targets, and quickly discover, identify, and track targets of concern; it is also suitable for fire protection, electricity, petroleum and other industries to achieve day and night monitoring of specific areas or equipment.


Technical parameter

Model Numberonick RM-312
Sensor TypeVOx Uncooled
Sensor Resolution384×288
Pixel Pitch12μm
NETD≤40mk
Frame Frequency50Hz
Objective Lens35mm
Angle of View7.5°×5.6°
Continuous Digital Zoom3.4X~13.6X
Eye Relief48mm
Diopter of Eyepiece±4
Display typeOLED
Color PaletteWhite Hot/Black Hot/Ironbow/Glowbow/Sepia/Red Hot/Green Hot
Detection Distance1800m
(Human, 1.8m)
Adjust Accuracy0.12mil
Adjust Range62.5ⅹ46.6mil
Reticle Type10 types
Video Resolution1024×768
Video Formatavi
Built-in Memory32GB
Wireless ProtocolWi-Fi
Wireless Standard802.11b/g/n
Frequency2.4GHz
Connection range10m
Battery Type18650 Battery×2
Capacity6400mAh
Operating time≥10hrs.
Max. Recoil power on rifles6000J
Shock resistance on the smooth-bore rifles12
Mounting rail typePicatinny
Body MaterialAluminum alloy
Weight535g
(Mount & Eyeshade excluded)
Length150mm
(Mount & Eyeshade excluded)
Degree of Protection, IP codeIP67
Operating Temperature-25℃~+50℃
Storage Temperature-40℃~+60℃
