RM-612 Rifle Infrared Sight

RM-612 Rifle Infrared Sight

Onick RM-612 It forms an image by detecting the thermal radiation emitted by the target object itself. Any object with a temperature above absolute zero will emit infrared rays. The intensity and wave
Send Inquiry
Description
Parameter
Products Description

Onick RM-612 It forms an image by detecting the thermal radiation emitted by the target object itself. Any object with a temperature above absolute zero will emit infrared rays. The intensity and wavelength of the infrared rays radiated will be different at different temperatures. Thermal imaging scopes use this feature to convert the thermal radiation distribution on the surface of an object into electrical signals, which are then processed and converted to form a visible thermal image on the display. This kind of scope is not affected by ambient light and can work effectively even in harsh conditions such as complete darkness, dense fog, and smoke. It is not easy to be discovered and has strong concealment.


Product features:

1. Supports photo and video evidence collection functions, and can record video images for a long time;

2. Built-in laser ranging module, supports 2000m laser ranging, with high ranging accuracy;

3. Long standby time, built-in rechargeable battery, continuous working time can reach 8 hours;

4. Small and light, low power consumption, simple operation, light and portable appearance structure, ergonomic structure;

5. Fast start-up, simple operation, compact and stable structure, protection level IP67;


Application areas:

Can record and take pictures, can record and restore the scene, can be used in patrol, law enforcement, search and rescue, drug and smuggling, prisoner pursuit and other scenes. It is suitable for special forces such as public security, armed police, and the military to achieve effective all-weather observation of specific areas or targets, and quickly discover, identify, and track targets of concern; it is also suitable for industries such as fire protection, electricity, and petroleum to achieve day and night monitoring of specific areas or equipment.


Technical parameter


Model Numberonick  RM-612
Sensor TypeVOx Uncooled
Sensor Resolution640×512
Pixel Pitch12μm
NETD≤40mk
Frame Frequency50Hz
Objective Lens42mm
Angle of View10.4°×8.3°
Continuous Digital Zoom2.4X~19.2X
Eye Relief48mm
Diopter of Eyepiece±4
Display typeOLED
Color PaletteWhite Hot/Black Hot/Ironbow/Glowbow/Sepia/Red Hot/Green Hot
Detection Distance2000m
(Human, 1.8m)
Adjust Accuracy0.18mil
Adjust Range87.07×69.72mil
Reticle Type10 types
Video Resolution1024×768
Video Formatavi
Built-in Memory32GB
Wireless ProtocolWi-Fi
Wireless Standard802.11b/g/n
Frequency2.4GHz
Connection range10m
Battery Type18650 Battery×2
Capacity6400mAh
Operating time≥10hrs.
Max. Recoil power on rifles6000J
Shock resistance on the smooth-bore rifles12
Mounting rail typePicatinny
Body MaterialAluminum alloy
Weight760g
(Mount & Eyeshade excluded)
Length182mm
(Mount & Eyeshade excluded)
Degree of Protection, IP codeIP67
Operating Temperature-25℃~+50℃
Storage Temperature-40℃~+60℃


RM-612 Rifle Infrared Sight

RM-612 Rifle Infrared Sight

RM-612 Rifle Infrared Sight

RM-612 Rifle Infrared Sight

RM-612 Rifle Infrared Sight

RM-612 Rifle Infrared Sight
