RM-612 LRF Intelligent Infrared Rangefinder Riflescope

RM-612 LRF Intelligent Infrared Rangefinder Riflescope

Onick RM-612 LRF intelligent infrared rangefinder riflescope applies artificial intelligence technology to the field of observation and aiming, and adopts the first automatic zero calibration and single-key menu control patented technology, which is suitable for day and night observation of targets under various complex backgrounds.
Send Inquiry
Description
Parameter
Products Description

Onick RM-612 LRF intelligent infrared rangefinder riflescope applies artificial intelligence technology to the field of observation and aiming, and adopts the first automatic zero calibration and single-key menu control patented technology, which is suitable for day and night observation of targets under various complex backgrounds. The built-in ranging module can quickly and accurately measure the distance of the target, provide precise parameter support for shooting, and improve the shooting hit rate. It adopts a 12μm detector, with two resolutions of 384×288/640×512 to choose from, with a 35/50mm focal length objective lens and a 1024×768 AMOLED display. Built-in ranging module, ranging range 10 - 800m, accuracy of ±1m, with BC automatic trajectory calculation function。


Product Features:

1. All-weather combat capability: not affected by darkness and bad weather (such as fog, rain, and snow), and can quickly detect and aim at targets under various environmental conditions.

2. Good concealment: Infrared thermal imaging technology passively receives infrared radiation from the target, does not need to emit visible light or other easily detectable signals, and is not easy to expose its own position.

3. Accurate ranging: The built-in ranging module can quickly and accurately measure the distance of the target, provide accurate parameter support for shooting, and improve the shooting hit rate.

4. Intelligent functions: Some high-end products have intelligent image processing functions, such as automatic target recognition, tracking, and trajectory calculation. It can also connect and share data with other devices (such as mobile phones, computers, etc.), making it convenient for combat personnel to obtain more information and conduct coordinated operations.


Application areas:

1. Military field: used for weapon aiming, reconnaissance, patrolling and other tasks, helping soldiers to find enemies and determine target locations at night or in harsh environments, and improve combat effectiveness.

2. Law enforcement field: law enforcement personnel can use it for night patrols, tracking suspects, searching for missing persons and other tasks to enhance the safety and effectiveness of law enforcement operations.

3. Hunting field: hunting enthusiasts use thermal imaging scopes to track prey at night or in low visibility conditions to increase the success rate of hunting.

4. Security monitoring field: can be installed in important areas such as buildings and public places to achieve real-time monitoring of the surrounding environment and timely detect abnormal situations and potential threats.


Technical parameter

Model Number RM-612 LRF
Sensor
Sensor Type VOx Uncooled
Sensor Resolution 640×512
Pixel Pitch 12μm
NETD ≤30mk
Frame Frequency 50Hz
Optics
Objective Lens 50mm
Angle of View 8.8°×7.0°
Continuous Digital Zoom 2.8X~22.4X
Eye Relief 48mm
Diopter of Eyepiece ±4
Display
Display type AMOLED
Resolution 1024*768
Pallete White Hot/Black Hot/Ironbow/Glowbow/Sepia/
Red Hot/Green Hot
Detection Range
Detection Distance 2600m
(Human, 1.7m)
Reticle
Adjust Accuracy 0.15mil
Adjust Range 73.2ⅹ58.6mil
Reticle Type 10 types
Video Recorder
Video Resolution 1024*768
Video Format mp4/jpg
Built-in Memory 32GB
WIFI
Wireless Protocol Wi-Fi
Wireless Standard 802.11b/g/n
Frequency 2.4GHz
Connection range 10m
Laser Rangefinder
Laser Wavelength 905nm
Measuring Accuracy ±1m
Measuring Distance 1000m
Laser Pointer
Power 5mW
Power Supply
Output Voltage 3~4.2V
Battery Type Built-in 18650 Batteryⅹ2, External 18500 Batteryⅹ1,
Capacity 6400mAh (Built-in) + 2000mAh (External)
Operating time ≥12hrs.
External power voltage 5V
Charging hours Approx. 5hrs
Build-in Battery charging temperature 0~45℃
Connections and Compatibilities
Max. Recoil power on rifles 6000J
Shock resistance on the smooth-bore rifles 12
Mounting type 30mm scope ring
Physical Characteristics
Body Material Aluminum alloy
Weight 1070g
(Mount & Eyeshade excluded)
Length 362mm
(Mount & Eyeshade excluded)
Environmental Characteristics
Degree of Protection, IP code IP67
Operating Temperature -25℃~+50℃
Storage Temperature -40℃~+60℃
