The long-distance laser rangefinder can measure quickly, automatically focus, measure distance, accurately calculate the average value, and has a powerful data storage function. It has optional azimuth and pitch angle functions, a wide range of functions, a small size, easy to carry, and easy to operate. It is widely used in industries such as rivers, waterways, benchmarks, telecommunications, cables, geological surveys, meteorology, airports, forests, etc.

1. Product features:

The distance measurement accuracy is up to 1 meter;

With gating function, the minimum range channel can be set; with average distance measurement function (AGV);

With standard RS232 serial port, it can also be equipped with Bluetooth and PDA, and the computer can be connected to transmit data;

It can store and view measurement data, and has data sending, data retrieval, data deletion and lighting functions;

Optional: with azimuth and pitch angle functions, displaying the horizontal distance and vertical distance of the target, and the pitch angle display range is ±45°; azimuth, azimuth is 360° display, N000.0° is displayed in the north, and gradually increases to the east, with a maximum of N359.9°;

Application areas: power, industry, forestry, security, geological exploration, construction, outdoor hunting, camping and mountaineering, etc.

II. Distance measurement parameters

Maximum range: 20000m

Effective range: 100-20000m

Distance measurement error: ±1m 100-5000 m ±2m 5000-10000 m

±3m 10000-15000 m ±5m 15000-20000 m

Compass accuracy: 0.5 degrees (RMS) optional

Tilt accuracy: 0.1 degrees (RMS within ±25 degrees) optional

Accuracy: 98%

Distance selection: 20~5120m (step length is 10m)

Maximum repetition frequency: 1/6Hz (10 times/min)

III. Distance measurement function

(1) Calculate the average value of measurement data

(2) Storage of measurement data (1000 data)

(3) Send measurement data (output interface: RS232, 2400, 8, N, 2)

(4) LCD display and reticle illumination and brightness adjustment, automatically shut down if no operation is performed for 20 seconds.

(5) Instrument service life statistics

(6) Query of the last ten distance measurements

IV. Optical parameters

Receiving aperture ￠: 42mm

Sight magnification: 12X

Wavelength: 1.064μm

Output energy: ≥20mj

Service life: ≥20,000 times

Working temperature: -10℃~+50℃ (optional -40℃~+60℃)

Environmental adaptability: dustproof, waterproof, shockproof

Dimensions: 171mm*195mm*84mm

Weight: 1.4kg

Power supply: polymer lithium battery pack (11.1V, 2200mAh) At room temperature, each fully charged battery pack can measure distances for more than 3,000 times.

V. Installation and Use

If you need to measure long-distance targets stably and reliably, you can fix it on the camera stand through the 1/4 screw hole on the bottom connecting plate of the instrument, or connect it to various theodolites through the dovetail groove on the connecting plate through a special adapter mechanism, and perform remote distance measurement operations through an external trigger cable.

VI. Battery

①This instrument uses a 11.1V, 1000mAh lithium battery.

②When the instrument shows that the battery is undervoltage, please charge or replace the special battery in time.

③To prevent injury or fire, do not let metal objects contact the battery electrodes.

④Please keep the battery dry.

⑤Do not put the battery in the fire (there is a risk of explosion if it is put in the fire).

⑥It is recommended to use the matching special charger to charge the battery pack. Using an inferior charger may cause damage to the battery pack.

⑦When charging the battery, please keep the ambient temperature between 0℃ and 40℃ and the relative humidity ≤80%. An inappropriate use environment may cause damage to the battery performance. (Note: When not in use for a long time, please store the dedicated battery pack in the packaging box, not in the rangefinder.)

VII. Charger Use

Insert the power output plug into the instrument socket, and then insert the power plug into the AC 100~240V power supply. Charge the lithium battery in the rangefinder.

VIII. Maintenance

① Check the appearance of the instrument frequently and remove dust, dirt, grease, mildew, etc. on the surface in time.

② Use a soft dry cloth to clean the eyepiece, objective lens or laser emission window. It is strictly forbidden to scratch with hard objects to avoid damaging the optical performance.

③ This machine is a high-precision instrument integrating light, machinery and electricity. It should be placed with care during use. It is strictly forbidden to squeeze or drop from a high place to avoid damaging the instrument.
