NVS-H3 is a head-mounted low-light night vision device for night patrols that can observe objects with binocular vision. It uses imported Gen3 image intensification tubes, high resolution, anti-glare and anti-dazzle functions, and built-in infrared auxiliary lighting source. The NVS-H3 is a monocular night vision system that uses a pseudo-binocular design for easy observation. It has a compact structure, small size and light weight. Multi-purpose: handheld, head-mounted. Product consultation: service@onick-optics.com

Functional features:

1. Advanced third-generation image intensifier, clearer and more layered images;

2. Strong light protection function, high light cut-off protection circuit, no fear of strong light exposure;

3. Available in completely dark environment, minimum focusing distance 0.25 meters, map can be viewed in completely dark environment;

4. Adjustable interocular distance (55-75mm), suitable for different face shapes;

5. Interchangeable high-power lens to enhance observation effect, three operating modes optional (3x/5x/8x);

6. Normal operation under temperature conditions of -45℃ to +50℃, adapt to extremely cold or extremely hot environments;

7. All-optical glass multi-layer coating, wide-angle infrared lighting, light weight, compact and sturdy goggles system;

8. Energy-saving power supply design, extended working time, low battery reminder.

Technical parameters:

Image tube level: third generation, OMNI III

Magnification: 1x

Field of view: 40°

Lens system: F1.2, 26.8mm

Resolution: 63-72lp/mm

Signal-to-noise ratio (typical): 23:1 or better

Cathode type: 18mm GaAs

Cathode sensitivity (typical): ≥1800μA/lm

Gain (typical): 45000-55000fl/fcd

FOM (typical): ≥1500

Eye distance adjustment: 55-75mm

Interocular distance: 15mm

Diopter: -6-+5dpt

Adjustment range: 0.25m-infinity

Effective distance: 300m

High light protection: yes

Auxiliary light source: yes

Infrared indicator: yes

Power supply: 1x3V CR123A lithium battery

Battery life: 40 hours

Image tube life: 12,000 hours

Low battery reminder: Yes

Relative humidity at 25° (%): up to 98%

Operating temperature: -40°C-+50°C

Storage temperature: -50°C-+70°C

Protection level: 2 meters 1 (optional)

Dimensions: 160x150x75mm

Weight: 560g
