Parameters for YBoptics Range Finder
Magnification | 6X |
Objective lens | 21MM |
Field of view | 7° |
Exit pupil diameter | 17.5mm |
Closest focusing distance | 5m |
LCD display | 12x12mm² |
LCD display transmittance | 85% |
Transmitting sensor type | 905nm laser diode |
Transmitting sensor power | 75W |
Receiving sensor type | Avalanche diode |
Field of view | 7° |
measurement accuracy | +/- 1M |
Ranging range | 5～700M/ 5～1000M/ 6～1500M |
Speed range | 0～300KM |
size | 105*82*43/ 105*75*45 |
weight | 235g |
battery | 3V (CR2) |
rainproof | Yes |
Operating temperature | -10° ~50° |
Shutdown | 20s no operation automatic shutdown |
focusing | Eyepiece focusing |
Coating | All lenses are coated with broadband green film |
Prism | BAK4 prism |
The 6x rangefinder is safe to the eyes and the body by using 905nm laser and multi coating lens. And It is widely used in tourist sightseeing, golf course, wild hunting, outdoor camping, power system inspection and maintenance, inspection line, forestry, mining, etc. It is a good helper for measuring target distance.
High measurement performance:
The performance is 5 to 700 meters, and it also has a high reflection target of 1200 meters.
Outstanding Features:
Measure distance, speed, mast lock, fog mode, continuous scan measurement.
Easy to use:
One touch measurement, one touch change mode. After 15 seconds of inactivity, it will automatically turn off.
Extremely compact:
It is the same size as a small chocolate bar and fits well in the palm and pocket.
