Product features:

Measure the height of 6 cables at the same time;

Applicable to cables of different purposes, small size, easy to carry;

Use large measuring head, higher accuracy than existing height gauges on the market;

Convenient measurement, easy to align cable position and view measurement results;

Measure the distance between cables, record measurement conditions: location, time, temperature;

PC software: allows you to analyze the changes in cable height over time and temperature throughout the year, and find patterns (optional);

With self-calibration function, measure the size of the room and the distance from one object to another;

Application areas: power, communication transmission cable measurement, electric locomotive cables and trolleybuses, large industrial enterprises, power transmission cables, electric cable measurement, and construction sites, trees, tower level and height measurement.

Product parameters:

Measuring range: (minimum cable diameter 25mm) 3 to 30m

Measuring range: (minimum cable diameter 12mm) 3 to 15m

Measuring range: (minimum cable diameter 5.5mm) 3 to 12m

Measuring range: (minimum cable diameter 2.5mm) 3 to 10m

Operating temperature range: -10℃ to 40℃

Measurement resolution: (measurement range <10m) 5mm

Measurement resolution; (measurement range >10m) 10mm

Measurement accuracy: 0.5%±2d

Minimum spacing between cables: 150mm

BTM mode: measure the distance of the lowest 6 cables V

TOP mode: measure the distance of the highest 6 cables V

CAL mode: self-calibration V

Automatic shutdown: V

Low power warning: V

Metric and imperial selection: V

Display real-time temperature: V
